ANSCHLUSSFELDER BREAKOUT

19"-1HE ALU-NATUR-ELOX. (PULVERN RAL-TON OPTIONAL)

MODULARE ANSCHLUSSFELDER

UNIVERSAL, TASCAM, RIEDEL(KDO), CLEARCOM(KDO)
DHD, LAWO, GHIELMETTI

UNIVERSAL LAWO TASCAM CLEARCOM (KDO) DHD GHIELMETTI RIEDEL (KDO) SIEMENS

MODULAR AF

AF4101 XLR Anschlußfeld 8xXB3 > 2xRJ45 8xXS3 > 2xRJ45	AF4101 [93 KB]
AF4102 XLR Anschlußfeld 16xXB3 > 4xRJ45	AF4102 [145 KB]
AF4103 XLR Anschlußfeld 16xXS3 > 4xRJ45	AF4103 [93 KB]
AF4104 XLR Anschlußfeld 4xXB3 > 4xRJ45 / 4xXS3 > 4xRJ45	AF4104 [72 KB]
AF4114 XLR Anschlußfeld 8xXB3 + 8xXS3 > 4xRJ45	AF4114 [93 KB]
AF4115 XLR Anschlußfeld 8xXS3 + 8xXB3 > 4xRJ45	AF4115 [97 KB]

AF4131 D-SUB-15	AF4131 [157 KB]
AF4132 D-SUB-15	AF4132 [156 KB]
AF4156 AA	AF4156 [144 KB]
AF4157 AES59	AF4157 [149 KB]
AF4158 DD	AF4158DD [150 KB]
AF4159 MIK	AF4159 [145 KB]

AF4116 XLR Anschlußfeld 16xXB3 COMBO > TASCAM	AF4116 [90 KB]
AF4121 XLR Anschlußfeld 8xXB3, 8xXS3	AF4121 [79 KB]
AF4151 XLR Anschlußfeld 16xXB3 TASCAM	AF4151 [80 KB]
AF4152 XLR Anschlußfeld 16xXS3 TASCAM	AF4152 [78 KB]

AF4100 XLR Anschlußfeld Clearcom 8x XB3+XS3 > RJ45

AF4100 [72 KB]

AF4140 DHD O-I-A	AF4140 [172 KB]
AF4148 DHD O-I-x	AF4148 [126 KB]

AF4149 / GHIELMETTI 16 x XB3	AF4149 [128 KB]
AF4150 / GHIELMETTI 16 x XX3	AF4150 [130 KB]

AF4119 RIEDEL INTERCOM

AF4119 [100 KB]

AF4133 SIEMENS 10XB3	AF4133-NDR [42 KB]
AF4134 SIEMENS 10XS3	AF4134-NDR [43 KB]
AF4135 SIEMENS 10XS3 + 10XXB3	AF4135-NDR [63 KB]
